V100 License Plate Recognition Camera

Support cloud deployment, web cross-platform remote access and debugging
Built-in license plate recognition CNN algorithm
Super starlight camera, suitable for harsh light environments
Support black and white list management
Can save pictures through SD card
Application: Parking lot management, license plate recognition, vehicle detection, etc.

  Product specifications

Technical Parameters



Data communication

Processor

Special license plate recognition chip

Interface

RJ45、GPIO、RS485、USB、SD

Sensor type

1/2.8" progressive scan CMOS

Power supply range

12V

Recognition rate

≥99.7%

Working power

≤7.5W

Trigger mode

Video trigger, coil trigger, car interception rate 99.7%

Development environment



Picture output

2 megapixel jpeg

SDK

Demo software, API, examples, user manual

Video compression format

H264,H265,MJPEG

Development language

C#, Delphi, java, Python, VB, etc.

Physical parameters



Http Post

support

Shell

Die-cast aluminum + sheet metal

special function

Can be done via remote upgrade

Size

160.7*210*29mm

working environment



Net weight



IP protection level

IP65

Package Size



Operating temperature

-25℃~+70℃





Working humidity

≤90% (no condensation)



  Detailed display



Power & Communication & GPIO (3.81mm plug-in terminal) wiring definition

Function

power supply

RS485

symbol

VCC

GND

A1

B1

GND

illustrate

12V±5%

Ground

Differential signaling

Differential signaling

Ground

GPI

GPO

IN1

IN2

Gnd

O1+

O1-

O2+

O2-

The input terminal can be grounded

The input terminal can be grounded

Ground

Relay output

Relay output

Relay output

Relay output
